High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling Featured Image
  • High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling
  • High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling
  • High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling
  • High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling

High Carbon Steel Hex Shank Wood Spade Drill Bit Titanium Coated For Woodworking Precision Drilling

Short Description:

  •   > High Grade Carbon Steel
  •   > Ground Tri-point Cutters and Twin Side Cutters
  •   > Fast Drilling in Wood, Chipboard and Plasterboard
  •   > Ideal for Door Locks, Electrical and Plumbing work.


Product Detail

Product Tags

Product Parameters

Product Name Spade Drill Bits For Wood Drilling
Material High Carbon Steel with Heat Treatment
Shank Type Hex shank ,Quick Change Hexagon Shank are available
Head Tip Tri-Point with Cutting Groove ,Center Point and Tri-Point are available
Surface Finish Bright ,Black oxide and Titanium Coating are available
Package  One Piece in One PVC Pouch or PVC Skin Card  or Paper Sandwich  or Double Blister
Features 1. Expert quality, manufactured from 45#special carbon steel hardened and tempered.

2. Full-length heat treatment guards against bending bit in heavy-duty applications.

3. Precision ground central point with optimized design for faster cutting performance.

4. Double cutting spurs scribe the outside of the hole reducing breakout.

5. Chisel edge design is more positively angled and digs into the wood.

6. Quick-change shank reduces slipping in standard chucks and is compatible with all 1/4" quick-change chucks and Extension, including impact drills.

7. Designed to perform fast, clean cuts, will bore all types of timber and are equally efficient when drilling with or against the grain.

8. Hang hole allows for bit storage & wire pulling.

Product Size

Bit Size

Hex Shank

Overall Length

Hole Diameter

1/4" x 6"

1/4"

6"

1/4"

5/16" x 6"

1/4"

 6"

5/16"

3/8" x 6"

1/4"

6"

3/8"

7/16" x 6"

1/4"

6"

7/16"

1/2" x 6"

1/4"

6"

1/2"

9/16" x 6"

1/4"

6"

9/16"

5/8" x 6"

1/4"

6"

5/8"

11/16" x 6"

1/4"

6"

11/16"

3/4" x 6"

1/4"

6"

3/4"

13/16" x 6"

1/4"

6"

13/16"

7/8" x 6"

1/4"

6"

7/8"

15/16" x 6"

1/4"

6"

15/16"

1" x 6"

1/4"

6"

1"

1-1/8" x 6"

1/4"

6"

1-1/8"

1-1/4" x 6"

1/4"

6"

1-1/4"

1-3/8" x 6"

1/4"

6"

1-3/8"

1-1/2" x 6"

1/4"

6"

1-1/2"

Hold Dia Size

Overall length

Flute length

Shank length

Shank diameter

8mm

150mm

32mm

8mm

6.2mm

10mm

150mm

32mm

8mm

6.2mm

12mm

150mm

35mm

8mm

6.2mm

13mm

150mm

38mm

8mm

6.2mm

14mm

150mm

38mm

8mm

6.2mm

16mm

150mm

38mm

8mm

6.2mm

18mm

150mm

38mm

8mm

6.2mm

19mm

150mm

38mm

8mm

6.2mm

20mm

150mm

38mm

8mm

6.2mm

22mm

150mm

38mm

8mm

6.2mm

24mm

150mm

45mm

8mm

6.2mm

25mm

150mm

45mm

8mm

6.2mm

30mm

150mm

54mm

8mm

6.2mm

32mm

150mm

54mm

8mm

6.2mm

34mm

150mm

54mm

8mm

6.2mm

35mm

150mm

54mm

8mm

6.2mm

Application

1,For the rapid drilling and forming of large diameters,in all types of wood.

2,Also suitable for most types of wood and wood-based panels.

3,Ideal for the installation of locks, electrical and plumbing work.

Our Advantages

-We have larger warehouse to shock products for delivery on time.

-We have professional sale and technology team to serve our customers to ensure your shopping experience

-Stable quality and widely use for hole drilling in hard material;

-Because our is factory,we can supply competitive price.

-The samples are free,freight is collected.If we can have your order ,we will decrease the freight cost from our first order.

our company6

Shipping and Packing

Shipping: Express delivery, air shipping, sea shipping are available for your request. Usual delivery time is 5-10days after receiving the advance payment; For the customized product, 15-30 days after receiving the advance payment.

Packing: We also supply single pvc bag,paper bag,colored plastic square box,transparent plastic box,skin card,sandwich and so on packages with size, logo,brand and other information.

packing-1
packing-2

FAQ

Q:Are you professional manufacturer of HSS twist drill bits?
A:Yes，JIANGSU HAOKE METAL TECH CO,.LTD is a professional factory that main products is HSS TWIST DRIL BITS.Following took a few photos of our workshop production and warehouse.

Q: Is OEM available?
A: Yes, OEM and customization are available. Graved logo marker,Laser logo marker,, customized packing. Printed Inner box, Carton box.

Q: Are samples available?
A: Yes, you can ask some samples for testing after confirming our prices, but please pay the sample and freight fee, the sample fee will be returned to you after you making official order.

Q: What is your payment terms?
A: T/T,L/C,D/A,D/P,Paypal,Western Union,for different circumstances.

Q: What's your delivery way?
A: Express delivery, air shipping, sea shipping are available for your request.

Q: What's your delivery time?
A: Usual delivery time is 5-10days after receiving the advance payment; For the customized product, 15-30 days after receiving the advance payment.
