High quality DY Carbide SDS Plus drill bit for stone, masonry drilling

Short Description:

Masonry drill bit is wildly used stone,concrete,brick,granite ,hard wood,due to it’s special material of tungsten carbide tip.

The fluted design of masonry drill bits allows for efficient removal of debris from the hole being drilled, preventing the bit from getting clogged and reducing heat build-up.

The shank of the masonry drill bit is usually designed to fit into a hammer drill or rotary hammer, allowing for faster and more accurate drilling.


Product Detail

Product Tags

Product Information

Product Name

High quality DY Carbide Masonry drill bit

Material

DY Carbide

Process

Milled

Suitable

Break/Concrete/Granite

Customize

 OEM&ODM customize Service

Shank type

Shank Design: SDS Plus Shank ,MAX shank ,Round Shank
The shank of the masonry drill bit is usually designed to fit into a hammer drill or rotary hammer, allowing for faster and more accurate drilling.

Size

Diameter: 4-40mm,

Total length: 70-1200mm

Working length:40-1140mm

Brazing Temp

High-temperature brazing at about 1,120º

Tips

Tungsten Carbide Tip

Package

in PVC Pouch, Plastic Box, Individually in Skin Card, Double Blister, Clamshell, Metal Box

Features

1.Wildly used :The masonry drill bit is suitable for almost all materials to be drilled (such as ,masonry ,concrete,stone,brick,hard wood,steel,and soon  )due to the special cutting edge geometry and the diamond-ground cutting surfaces of the carbide tip

2.Durability: Masonry drill bits are designed to be durable and long-lasting, even when used on tough materials like concrete and brick
3.Fit machine :Fits directly into all hammer drilling machines with SDS-plus and HILTI TE-C drive

Payment terms

T/T,L/C,D/A,D/P,Paypal,Western Union,for different circumstances.

Note :

*To fit all rotary hammer with SDS-PLUS chuck,Lubracation oil is recommended on shank.*Rotary speed RPM1000 to 2600 with hammer impact up to the drill diameter applications.
*No for reinforced concrete with steel bar.

Product Size

YG8C drill bit size

Diameter

Flute Length

Overall Length

D mm inch

L1 (mm)

L2(mm)

3

1/8

30

60

4

5/32

40

75

5

3/16

50

85

6

15/64

60

100

6.5

1/4

60

100

7

9/32

60

100

8

5/16

80

120

9

11/32

80

120

10

3/8

80

120

11

7/16

85

150

12

15/32

85

150

13

1/2

95

150

14

9/16

95

150

15

19/32

95

150

16

5/8

95

150

17

11/16

95

150

18

11/16

105

160

19

3/4

105

160

20

25/32

105

160

22

7/8

105

160

24

15/16

105

160

25

1

105

160

Product Details

YG8C drill bit details.png

Product Applications Scene

The masonry drill bit is suitable for almost all materials to be drilled ,such as, masonry, concrete,stone,brick,granite, hard wood, steel, and soon.

YG8C drill bit application-1
YG8C drill bit application-2
YG8C drill bit application-3

Shipping and Packing

Shipping: Express delivery, air shipping, sea shipping are available for your request. Usual delivery time is 5-10days after receiving the advance payment; For the customized product, 15-30 days after receiving the advance payment.

Packing: We also supply single pvc bag,paper bag,colored plastic square box,transparent plastic box,skin card,sandwich and so on packages with size, logo,brand and other information.
