HSS M35 Cobalt Jobber Length straight shank Twist Drill Bits For Stainless Steel Metal Drilling

Short Description:

1.Faster and longer life -Cobalt drill bits last longer and cut faster than standard high speed steel bits.

2.Wild used-Maximum speed and life in stainless steel and other hard, tough materials .

3. Efficient drilling-135°split point for precision start no walking.

4.OEM/ODM -Accept custom.


Product Detail

Product Tags

Product Description

Product Name

HSS M35 Cobalt Jobber Length straight shank Twist Drill Bits For Stainless Steel Metal Drilling

 4.hss twist  drill bit  detail picture

Material

4241/4341/6542/M35

Standard

ANSI standard  Jobber length size

Shank

Straight shank

Size

D:3/64"-11/16’’  F:3/4"--5-5/8", T:1-3/4"--7-5/8"

Package

plastic box

Application

Light-gauge metal, high-carbon steel, aluminum and ally steel, cast iron, stainless steel,cast iron, wood, plastic.

Features

1. Super sharp outlining spurs are ground at 135° to give you clean, accurate entrance holes with minimal blow out around exit holes.

2. Small relief grind on the point keeps the bit drilling straight, even in twisted and curly grain.Bits have straight shanks.

3. High hardness, strong wear resistance, special hit stainless steel .The surface is smooth and the grinding precision is high

4. Universal Round Drill Shank, widely used, clamping and fastening.

Points to note

1、The use of ceramic tile, concrete, wall, stone, etc. is prohibited.

2、Twist drill is a cutting tool, mainly used for metal drilling, so it is very important to control the speed.

3、When using manual drill, pay attention to adjust the rotation speed, the drill bit is easy to be damaged if the rotation speed is too fast.

4、This product can be re-ground for use.

5、When processing thick-bottomed products,if there is an abnormal of cutting,please remove the debris in time.

6、This product can not be used at the time of striking, the work must be fixed, the operation of the working swing will break the drill.

Product Size

size

ANSI and DIN338 standard jobber length sizes

Diameters

Overall length

Flute length

Diameters

Overall length

Flute length

mm

mm

mm

inch

inch

inch

0.5

22

6

3/64"

1-3/4"

3/4"

1.0

34

12.0

1/16"

1-7/8"

7/8"

1.5

43

20.0

5/64"

2"

1"

2

49

24.0

3/32"

2-1/4"

1-1/8"

2.5

57

30.0

7/64"

2-5/8"

1-1/2"

3.0

61

33.0

1/8"

2-3/4"

1-5/8"

3.2

65

36.0

9/64"

2-7/8"

1-3/4"

3.5

70

39.0

5/32"

3-1/8"

2"

4.0

75

46.0

11/64"

3-1/4"

2-1/8"

4.2

75

46.0

3/16"

3-1/2"

2-5/16"

4.5

80

47.0

13/64"

3-5/8"

2-7/76"

4.8

86

52.0

7/32"

3-3/4"

2-1/2"

5.0

86

52.0

15/64"

3-7/8"

2-5/8"

5.2

86

52.0

1/4"

4"

2-3/4"

5.5

93

57.0

17/67"

4-1/8"

2-7/8"

6.0

93

57.0

9/32"

4-1/4"

2-15/16"

6.5

101

63.0

19/64"

4-3/8"

3-1/16"

7.0

109

69.0

5/16"

4-1/2"

3-3/16"

7.5

109

69.0

21/64"

4-5/8"

3-5/16"

8.0

117

75.0

11/31"

4-3/4"

3-7/16"

8.5

117

75.0

23/64"

4-7/8"

3-1/2"

9.0

125

81.0

3/8"

5"

3-5/8"

9.5

125

81.0

25/64"

5-1/8"

3-3/4"

10.0

133

87.0

13/32"

5-1/4"

3-7/8"

10.5

133

87.0

27/64"

5-3/8"

3-15/16"

11.0

142

94.0

7/16"

5-1/2"

4-1/16"

11.5

142

94.0

29/64"

5-5/8"

4-3/16"

12.0

151

101

15/32"

5-3/4"

4-5/16"

12.5

151

101

31/64"

5-7/8"

4-3/8"

13.0

151

101

17/32"

6-5/8"

4-13/16"

13.5

160

108

35/64"

6-5/8"

4-13/16"

14.0

160

108

9/64"

6-5/8"

4-13/16"

14.5

169

114

37/64"

6-5/8"

4-13/16"

15.0

169

114

19/32"

7-1/8"

5-13/16"

15.5

178

120

39/64"

7-1/8"

5-13/16"

16.0

178

120

5/8"

7-1/8"

5-13/16"

16.5

184

125

41/64"

7-1/8"

5-13/16"

17.0

184

125

21/32"

7-1/8"

5-13/16"

17.5

191

130

43/64"

7-5/8"

5-5/8"

18.0

191

130

11/16"

7-5/8"

5-5/8"

18.5

198

135



19.0

198

135



19.5

205

140



20.0

205

140
