SDS Plus Shank Hammer Drill Bit YG8C Single Tip For Concrete Brick Stone

Short Description:

The drill body is made of 40CR chrome steel, and the head is made of thickened and widened YG8C carbide tip, processed by high-temperature heat treatment process, which makes the product reach a perfect combination of hardness and toughness, durable and not easy to break.


Product Detail

Product Tags

Product Information

Product Name Carbide Single Tip SDS Plus Hammer Drill Bit for Concrete
Body Material 40Cr Steel with Heat Treatment
Tip Material Tungsten Carbide
Process Milled Flutes and Welded Tip
Tip Type Single Tip
Flute Type S4 Flute,L Flute, U Flute
Shank  SDS Plus Shank
Surface Finish Sand Blasted
Package in PVC Pouch, Plastic Box, Individually in Skin Card, Double Blister, Clamshell, Metal Box
Features 1.Premium 40Cr steel with heat treatment improves core strength for maximum durability and extended life.
2.Hardened, premium carbide insert tip is strong and stays sharp longer for finer material break up and easier drilling.increases strength and durability.
3.Copper braze material gives high heat resistance for reduced tip loss,Carbide tip securely embedded in the steel body.
4.fold spiral flute (S4) for rapid drilling dust removal. With even less vibration and more precise guiding, the stability and service life of the drill bit are increased.



Product Size

SIZE(MM)



SIZE(MM)



SIZE(MM)



SIZE(MM)

4*110



14*260



10*450



25*800

5*110



16*260



12*450



26*800

6*110



18*260



14*450



28*800

6.5*110



20*260



16*450



30*800

7*110



22*260



18*450



32*800

8*110



24*260



19*450



35*800

9*110



25*260



20*450



40*800

10*110



26*260



22*450



10*1000

11*110



28*260



24*450



12*1000

12*110



30*260



25*450



14*1000

13*110



32*260



26*450



16*1000

4*160



6*310



28*450



18*1000

5*160



8*310



30*450



20*1000

6*160



10*310



32*450



22*1000

6.5*160



12*310



35*450



24*1000

7*160



14*310



40*450



25*1000

8*160



16*310



8*500



26*1000

9*160



18*310



10*500



28*1000

10*160



20*310



12*500



30*1000

11*160



22*310



14*500



32*1000

12*160



24*310



16*500



35*1000

13*160



25*310



18*500



40*1000

14*160



26*310



20*500





16*160



28*310



22*500





18*160



30*310



24*500





20*160



32*310



25*500





22*160



6*350



26*500





25*160



8*350



28*500





5*210



10*350



30*500





5.5*210



12*350



32*500





6*210



14*350



34*500





6.5*210



16*350



35*500





7*210



18*350



8*600





8*210



20*350



10*600





9*210



22*350



12*600





10*210



24*350



14*600





12*210



25*350



16*600





13*210



26*350



18*600





14*210



28*350



20*600





16*210



30*350



22*600





18*210



32*350



24*600





20*210



8*410



25*600





22*210



10*410



26*600





24*210



12*410



28*600





25*210



14*410



30*600





26*210



16*410



32*600





28*210



18*410



35*600





6*260



20*410



40*600





6.5*260



22*410



10*800





7*260



24*410



12*800





8*260



25*410



14*800





9*260



26*410



16*800





10*260



28*410



18*800





11*260



30*410



20*800





12*260



32*410



22*800





13*260



8*450



24*800







Custom-tailor would be available against customers’ requirements

Application

           Scope of application

material

Shipping and Packing

Shipping: Express delivery, air shipping, sea shipping are available for your request. Usual delivery time is 5-10days after receiving the advance payment; For the customized product, 15-30 days after receiving the advance payment.

Packing: We also supply single pvc bag,paper bag,colored plastic square box,transparent plastic box,skin card,sandwich and so on packages with size, logo,brand and other information.

packing
deliver

FAQ

Q: Is OEM available?
A: Yes, OEM and customization are available. Graved logo marker,Laser logo marker,, customized packing. Printed Inner box, Carton box.

Q: Are samples available?
A: Yes, you can ask some samples for testing after confirming our prices, but please pay the sample and freight fee, the sample fee will be returned to you after you making official order.

Q: What is your payment terms?
A: T/T,L/C,D/A,D/P,Paypal,Western Union,for different circumstances.

Q: What's your delivery way?
A: Express delivery, air shipping, sea shipping are available for your request.

Q: What's your delivery time?
A: Usual delivery time is 5-10days after receiving the advance payment; For the customized product, 15-30 days after receiving the advance payment.
